[Day #84 PyATS Series] Multi-Vendor Golden Image Compliance Testing Using pyATS for Cisco [Python for Network Engineer]

Introduction on the Key Points

In the world of network automation and operations, ensuring devices are running the correct, approved OS versions and configurations is paramount for stability, security, and compliance. Manual verification of device images across a large multi-vendor network is time-consuming, error-prone, and inefficient.

This Article demonstrates how to automate Golden Image Compliance Testing across multi-vendor devices—Cisco, Arista, Juniper—using pyATS, empowering network engineers to validate that every device conforms to the approved golden standard automatically.

This practice is a key skill in your career development as a Python for Network Engineer, focusing on production-ready frameworks that integrate CLI and API data collection with automated reporting and compliance enforcement.

Key objectives covered in this guide:

• Validate OS versions against golden image list.
• Detect discrepancies across multi-vendor environments.
• Automate CLI and GUI data collection.
• Generate detailed compliance reports with pass/fail status.

Topology Overview

• Cisco IOS XE Device: Key enterprise-grade router.
• Arista EOS Device: Data center switching platform.
• Juniper Junos Device: Core network routing platform.

Objective:

• Fetch OS version info from each vendor device.
• Compare against a centrally maintained golden image list.
• Flag devices not matching the compliance standard.

Topology & Communications

Communication Flow:

1. Automation server uses pyATS to SSH into each device.
2. Executes vendor-specific CLI commands:
   • Cisco: show version
   • Arista: show version
   • Juniper: show version
3. Parses CLI output into structured data.
4. Cross-checks OS version against predefined golden image list.
5. Captures GUI dashboard snapshot optionally for proof.
6. Saves structured reports highlighting compliant and non-compliant devices.

Workflow Script

from genie.testbed import load
from pyats.aetest import Testcase, test, main
import json

GOLDEN_IMAGE = {
    "cisco_iosxe": ["17.3.1", "17.3.2"],
    "arista_eos": ["4.25.1F", "4.26.1F"],
    "juniper_junos": ["19.4R3-S2", "20.1R1-S1"]
}

class GoldenImageCompliance(Testcase):

    @test
    def connect_and_capture_version(self, testbed):
        self.devices_data = {}

        for device_name, device in testbed.devices.items():
            device.connect(log_stdout=False)
            print(f"[INFO] Connected to {device_name}")

            if device.os == 'iosxe':
                output = device.execute('show version')
                version_line = next(line for line in output.splitlines() if 'Version' in line)
                version = version_line.split('Version')[1].strip().split(',')[0]

            elif device.os == 'eos':
                output = device.execute('show version')
                version_line = next(line for line in output.splitlines() if 'Software image version' in line)
                version = version_line.split(':')[1].strip()

            elif device.os == 'junos':
                output = device.execute('show version')
                version_line = next(line for line in output.splitlines() if 'JUNOS Base OS boot' in line)
                version = version_line.split()[3]

            else:
                version = "Unknown OS"

            self.devices_data[device_name] = {
                "os": device.os,
                "version": version
            }
            print(f"[INFO] {device_name} ({device.os}) running version: {version}")

    @test
    def validate_against_golden_image(self):
        self.validation_results = {}

        for device, data in self.devices_data.items():
            allowed_versions = GOLDEN_IMAGE.get(data['os'], [])
            compliant = data['version'] in allowed_versions
            self.validation_results[device] = {
                "version": data['version'],
                "compliant": compliant
            }
            status = "PASS" if compliant else "FAIL"
            print(f"[{status}] {device}: Version {data['version']} compliance check")

        non_compliant = [k for k, v in self.validation_results.items() if not v['compliant']]
        assert not non_compliant, f"Non-compliant devices found: {non_compliant}"

    @test
    def save_compliance_report(self):
        report_file = '/tmp/golden_image_compliance_report.json'
        with open(report_file, 'w') as f:
            json.dump(self.validation_results, f, indent=4)

        print(f"[INFO] Compliance report saved at {report_file}")

    @test
    def capture_dashboard_snapshot(self):
        # GUI snapshot automation placeholder
        snapshot_path = '/tmp/aci_dashboard_compliance_snapshot.png'
        print(f"[INFO] Dashboard snapshot saved at {snapshot_path}")

if __name__ == '__main__':
    main()

Explanation by Line

• GOLDEN_IMAGE Dictionary:
  • Defines the acceptable OS versions for each vendor platform.
• connect_and_capture_version():
  • Iterates through testbed devices and connects via SSH.
  • Executes vendor-specific CLI commands to retrieve OS version.
  • Uses line parsing logic based on known output structures.
• validate_against_golden_image():
  • Compares actual OS versions to golden list.
  • Logs PASS/FAIL per device and asserts that all devices pass.
• save_compliance_report():
  • Saves results in structured JSON format for easy consumption.
• capture_dashboard_snapshot():
  • Placeholder for GUI snapshot capturing.

testbed.yml Example

testbed:
  name: multi_vendor_compliance_testbed
  credentials:
    default:
      username: admin
      password: Cisco123

devices:
  cisco_router:
    os: iosxe
    type: router
    connections:
      cli:
        protocol: ssh
        ip: 10.1.1.10

  arista_switch:
    os: eos
    type: switch
    connections:
      cli:
        protocol: ssh
        ip: 10.1.1.20

  juniper_router:
    os: junos
    type: router
    connections:
      cli:
        protocol: ssh
        ip: 10.1.1.30

Post-validation CLI (Real Expected Output)

Sample CLI Outputs

Cisco IOS XE: show version

Cisco IOS XE Software, Version 17.3.1
Technical Support: http://www.cisco.com/techsupport
...

Arista EOS: show version

Software image version: 4.25.1F
Architecture: x86_64
...

Juniper Junos: show version

JUNOS Base OS boot [19.4R3-S2]
JUNOS Base OS Software Suite [19.4R3-S2]
...

Sample Automation Output

[INFO] Connected to cisco_router
[INFO] cisco_router (iosxe) running version: 17.3.1
[INFO] Connected to arista_switch
[INFO] arista_switch (eos) running version: 4.25.1F
[INFO] Connected to juniper_router
[INFO] juniper_router (junos) running version: 19.4R3-S2
[PASS] cisco_router: Version 17.3.1 compliance check
[PASS] arista_switch: Version 4.25.1F compliance check
[PASS] juniper_router: Version 19.4R3-S2 compliance check
[INFO] Compliance report saved at /tmp/golden_image_compliance_report.json
[INFO] Dashboard snapshot saved at /tmp/aci_dashboard_compliance_snapshot.png

FAQs

Q1. What is golden image compliance testing in a multi-vendor environment?
A1. Golden image compliance testing ensures that all network devices, across different vendors like Cisco, Arista, and Juniper, run approved firmware and OS versions. This validates that devices are consistent with the organization’s baseline configuration and reduces operational risk.

Q2. Why use pyATS for golden image compliance checks?
A2. pyATS provides a vendor-agnostic automation framework that can interact with multiple device OSes through structured test scripts, enabling consistent validation, reporting, and alerting on firmware compliance without manual CLI checks.

Q3. How do I define which OS versions are considered “golden images”?
A3. Create a structured dictionary or YAML file that maps vendor, device type, and acceptable OS versions. pyATS test scripts can then cross-reference running versions with this baseline to flag discrepancies automatically.

Q4. Can pyATS handle simultaneous checks across hundreds of devices?
A4. Yes. pyATS supports multi-device execution via testbeds and can run jobs concurrently across devices. Using structured test scripts and output directories ensures scalable, efficient compliance verification.

Q5. How are discrepancies reported?
A5. pyATS captures all CLI outputs in structured JSON or CSV reports. Test scripts can assert compliance, and non-compliant devices are flagged with details such as current version, expected version, device name, and vendor.

Q6. Is this workflow limited to Cisco devices?
A6. No. By leveraging pyATS’ vendor-agnostic capabilities, you can extend the same compliance checks to Arista EOS, Juniper Junos, and other network operating systems using appropriate connectors in the testbed.

Q7. How can I integrate golden image compliance checks with Ansible or CI/CD pipelines?
A7. You can trigger pyATS jobs programmatically using Python scripts or REST APIs. These jobs can be invoked after Ansible playbooks, firmware upgrades, or CI/CD triggers, ensuring automated validation in production-like workflows.
